AltarViewer

A graphical user interface application for launching and managing Omniboard instances to visualize and track MongoDB-backed experiments from the DREAM/Altar ecosystem.

Table of Contents

• Features
• Installation
  • Prerequisites
  • From Source
  • From Binary Release
• Usage
  • Quick Start
  • Configuration
• Development
  • Setting Up Development Environment
  • Running Tests
  • Building the Executable
• Architecture
• Contributing
• Troubleshooting
• Versioning
• License

docker –version

Features

• MongoDB Connection Management: Connect to local, remote, or Atlas MongoDB instances (port or full URI)
• Database Discovery: Automatically list available databases
• One-Click Omniboard Launch: Deploy Omniboard in isolated Docker containers
• Web UI: Dash-based web application served in your browser
• Docker Integration: Automatic container management and cleanup
• Multi-Instance Support: Run multiple Omniboard instances on different ports
• Deterministic Port Assignment: Hash-based port generation preserves browser cookies per database
• Container Cleanup: Easy removal of all Omniboard containers

Installation

You can use any of these options:

Option 1 – Executable

Download the latest platform-specific launcher from the AltarViewer releases and run it.

Option 2 – Python app

git clone https://github.com/DreamRepo/Altar.git
cd Altar/AltarViewer
python -m venv venv

# Activate the venv (one of these)
venv\Scripts\activate      # Windows
source venv/bin/activate    # macOS/Linux

pip install -r requirements.txt
python -m src.main

Option 3 – Docker image

docker pull alienor134/altarviewer:latest
docker run -d \
  -p 8060:8060 \
  -v /var/run/docker.sock:/var/run/docker.sock \
  -e MONGO_DEFAULT_URL="mongodb://<mongo-host>:27017/" \
  --name altarviewer \
  alienor134/altarviewer:latest

Replace <mongo-host> with the host where MongoDB is reachable from the container (for example host.docker.internal on Docker Desktop).

Option 4 – Docker Compose (AltarDocker stack)

Use AltarDocker to spin up MongoDB and MinIO, then point AltarViewer to that MongoDB:

git clone https://github.com/DreamRepo/AltarDocker.git
cd AltarDocker
docker compose -f docker-compose_default.yml up -d

Then start AltarViewer via option 1–3 and connect it to the MongoDB instance from the stack (for example mongodb://localhost:27017).

Usage

Quick Start

1. Launch the application (using any install option above)

2. Open the web app
   • In your browser, go to http://localhost:8060 to reach the AltarViewer UI.
3. Connect to MongoDB
   • Enter your MongoDB host and port (default: localhost:27017)
   • Click “Connect” to list available databases
4. Select a database
   • Choose a database from the dropdown list
   • Click “Launch Omniboard”
5. Access Omniboard
   • A clickable link will appear in the interface
   • Omniboard opens automatically in your default browser

Configuration

MongoDB Connection

• Default Port: 27017
• Connection String: Supports standard MongoDB URIs
• Authentication: Configure in MongoDB settings (currently local connections)

Port Management

• Deterministic Port Assignment: Ports are generated using a hash of the database name (base: 20000, range: 10000)
• Browser Cookie Preservation: The same database always gets the same port, preserving Omniboard customizations and cookies in your browser
• Automatic Conflict Resolution: If the preferred port is unavailable, the next free port is automatically selected
• Port Range: 20000-29999 (based on SHA-256 hash of database name)

Development

Setting Up Development Environment

1. Clone and setup

   git clone https://github.com/DreamRepo/Altar.git
   cd Altar/AltarViewer
   python -m venv venv
   source venv/bin/activate  # or venv\Scripts\activate on Windows


2. Install development dependencies

   pip install -r requirements.txt
   pip install -r requirements-dev.txt


Running Tests

# Run all tests
pytest

# Run with coverage
pytest --cov=src --cov-report=html

# Run specific test file
pytest tests/test_mongodb.py

# Run with verbose output
pytest -v

Building the Executable

Build a standalone executable using PyInstaller:

# Install PyInstaller (if not in requirements-dev.txt)
pip install pyinstaller

# Build executable
pyinstaller OmniboardLauncher.spec

# Output will be in dist/ directory

Customizing the Build

Edit OmniboardLauncher.spec to customize:

• Application name and icon
• Bundled data files
• Hidden imports
• Build options

Architecture

AltarViewer/
├── src/
│   ├── main.py          # Application entry point
│   ├── gui.py           # GUI implementation (CustomTkinter)
│   ├── mongodb.py       # MongoDB connection logic
│   └── omniboard.py     # Docker/Omniboard management
├── tests/
│   ├── conftest.py      # Pytest configuration
│   ├── test_mongodb.py  # MongoDB tests
│   └── test_omniboard.py # Omniboard tests
├── assets/              # Images and resources
├── requirements.txt     # Production dependencies
├── requirements-dev.txt # Development dependencies
└── OmniboardLauncher.spec # PyInstaller specification

Key Components

• GUI Layer (gui.py): CustomTkinter-based interface
• MongoDB Layer (mongodb.py): Database connection and queries
• Omniboard Layer (omniboard.py): Docker container management with hash-based port assignment
• Main Controller (main.py): Application orchestration

Port Assignment Algorithm

The application uses a deterministic hash-based port assignment:

port = 20000 + (SHA256(database_name) % 10000)

This ensures:

• Consistency: Same database → same port
• Browser Persistence: Cookies and customizations are preserved
• Conflict Handling: Automatic fallback to next available port if needed

Contributing

We welcome contributions! Please follow these guidelines:

Getting Started

1. Fork the repository on GitHub
2. Clone your fork locally

   git clone https://github.com/YOUR_USERNAME/Altar.git
   cd Altar/AltarViewer


3. Create a feature branch

   git checkout -b feature/your-feature-name


Development Workflow

1. Make your changes
   • Follow PEP 8 style guidelines
   • Add tests for new features
   • Update documentation as needed
2. Run tests and linting

   pytest


3. Commit your changes

   git add .
   git commit -m "feat: add your feature description"


   Use Conventional Commits:

   • feat: New feature
   • fix: Bug fix
   • docs: Documentation changes
   • test: Test additions or changes
   • refactor: Code refactoring
   • chore: Maintenance tasks
4. Push to your fork

   git push origin feature/your-feature-name


5. Create a Pull Request
   • Provide a clear description of changes
   • Reference any related issues
   • Ensure all tests pass

Troubleshooting

Connection Errors

Problem: “Connection Error” when connecting to MongoDB

Solutions:

• Ensure MongoDB is running: mongosh or mongo
• Check the port number (default: 27017)
• Verify firewall settings allow connections
• Check MongoDB logs for authentication issues

Docker Issues

Problem: Docker-related errors when launching Omniboard

Solutions:

• Verify Docker Desktop is running: docker ps
• Check Docker has sufficient resources allocated
• Ensure port 9005+ are not in use by other applications
• Try clearing old containers: Use the cleanup button in the app

Port Conflicts

Problem: “Port already in use” errors

Solutions:

• The application automatically finds the next available port if the preferred port is busy
• Use the “Clear Omniboard Docker Containers” button to remove old containers
• Manually check and stop containers:

  docker ps
  docker stop <container_id>


• Check for other applications using ports 20000-29999

Note: Each database consistently uses the same port (hash-based), allowing your browser to remember Omniboard customizations and preferences per database

Import Errors

Problem: Missing module errors when running from source

Solutions:

• Reinstall dependencies: pip install -r requirements.txt
• Ensure virtual environment is activated
• Check Python version compatibility (3.8+)

Getting Help

• Check existing GitHub Issues
• Review Omniboard documentation
• Contact the DREAM/Altar team

Release Process

1. Update version in relevant files
2. Create a git tag: git tag -a v1.0.0 -m "Release version 1.0.0"
3. Push tag: git push origin v1.0.0
4. Build and publish release manually (the tagged commit will only produce a draft release)

License

This project is licensed under the GNU General Public License v3.0 - see the LICENSE file for details.
